Professional Single Blade Hydraulic Sheeting Guillotine High Quality Program Control Paper Cutter

SQZK S16 High Speed Guillotine Cutters Techinical Parameter Floor Plan Computer System 16 inch Full touch display screen

Send your inquiry

DESCRIPTION

SQZK S16 High Speed Guillotine Cutters

Techinical Parameter
Floor Plan
Computer System

16 inch Full touch display screen,
German operating system is equipped to meet the operating habits of domestic users and guarantee convenient operation.
Mainboard adopts industrial chip imported from Italy
Highly sensitive of the touch screen has real-time responses;
Equipped with signal amplification function and excellent anti-interference to avoid dimension errors due to drive aging;
Dimension in front of knife will be displayed to facilitate sizes for cutting;
Program storage capacity is 300 programs, each program can store 200 items cutting size.
A paper-pushing program is equipped to push paper automatically so as to guarantee safety and enhance operation efficiency;
Automatic cutting can be made as per instructed programming;
Display precision is 0.01mm;

Machine Performance

Professional Single Blade Hydraulic Sheeting Guillotine High Quality Program Control Paper Cutter

Our Company

Model	Unit	92	115	130	137	168	188
Max.Cutting Width	cm	92	115	130	137	168	188
	inch	36.2	45.3	51.2	53.9	66.1	74
Max.Cutting Length	cm	92	115	130	145	168	188
	inch	36.2	45.3	51.2	57.1	66.1	74
Max. Cutting Height	mm	120	165	165	165	165	165
	inch	4.7	6.5	6.5	6.5	6.5	6.5
Min. Cutting Size(without false clam plate)	mm	25	30	30	30	30	30
	inch	1	1.2	1.2	1.2	1.2	1.2
Min. Cutting Size(with false clamp plate)	mm	90	90	90	90	90	90
	inch	3.5	3.5	3.5	3.5	3.5	3.5
Front Table Length	cm	63.2	71.5	73	73	75	75
	inch	24.9	28.1	28.7	28.7	29.5	29.5
Max.Clamp Pressure	N	30000	40000	40000	45000	60000	70000
Max. Cutting Speed	time/min	45	46	46	46	46	46
Main Motor	KW	3	4	4	4	8.5	8.5
Net Weight	Kg	2300	3700	3900	4100	6200	6600
Gross Weight	Kg	2500	4100	4300	4500	7000	7400
Packing Size(L×W×H)	cm	228×140×188	285×190×210	285×190×210	310×190×210	360×205×220	380205220
